Do you want to Produce electronics producsts - Using Through Hole ?
0 likes94 views
Shenzhen Southern Machinery Sales and Service Co., Ltd. is a Chinese company that manufactures and sells automated insertion machines including auto axial and radial inserters. Their auto radial inserter, model S-3000, can insert components at speeds up to 18,000 pieces per hour with dual and triple span capabilities from 2.5mm to 7.5mm. Their auto axial inserter, model S-4000, can insert components at speeds up to 24,000 pieces per hour with dual span capabilities from 5mm to 20mm. Both machines offer expandability from 20 to 100 stations and come with after-sales support services.
1 of 6
Download to read offline
